• Press Reset button for at least 6 seconds; Restart of the device is automatically executed; Default settings have been restored; Execute software reset. With the ASUS RT-N12 D1, you can restore the factory settings with the installed software.
  • Hide SSID: Yes No LAN IP: 192.168.1.1: PIN code: 12345670: MAC address: 00:90:4c:08:00:2d: WPS: Click the button to enable WPS mode. Click the button to enable WPS mode.

Wireless ASUS router Hard Factory Reset To reset your router to the factory default settings, you can Press and Hold the Reset button on your router. However, in some cases, this may not successfully reset the router to the default status. ASUS recommends that you try the Hard Factory Reset before attempting any advanced troubleshooting.

Here you can find the default IP address and the username and password for the user interface of the ASUS RT-N12HP Wireless-N300 3-in-1 router. This site also contains information about the preconfigured Wi-Fi settings of the device. In the bottom part of this website, you will find a manual for accessing the user interface of this router and resetting its factory settings.

Login data for the user interface

192.168.1.1
admin
admin

Preconfigured Wi-Fi settings

ASUS
<blank>

Access to the user interface

Accessing the user interface is necessary when you want to change the router configuration. For the ASUS RT-N12HP, you have to do the following steps for access:

  1. Switch on router
  2. Connect the device via Wi-Fi* or a network cable with the router
  3. Open web browser
  4. Enter IP address in the address bar and then confirm with ‘Enter’ key
  5. Enter username and password in the open interface and confirm once more

* Make sure that your router’s Wi-Fi is activated.

Reset default settings

Resetting default settings is especially helpful when you have changed and forgotten the login data for the user interface. Please consider that not only will settings like IP address, username and password be set to factory settings, but all configurations you may have made will as well.

Execute hardware reset

To reset the ASUS RT-N12HP to its default settings, you have to do the following steps:

  1. Turn on router
  2. For at least 6 seconds, press the Reset button
  3. Device is automatically restarted
  4. Router has been reset to factory settings

Execute software reset

With the ASUS RT-N12HP, you can restore the factory settings with the installed software. Log in to the user interface of the router with your access data and execute the steps that are described in the user handbook.

After you have successfully executed the steps mentioned above, the configuration of the router will be reset to factory settings. If you want to log in to the user interface, you have to use the preset login data.

Manuf (OEM/ODM):Arcadyan WG7005F22 1-ASU

FCC approval date: 12 May 2011
Country of manuf.: China

Amazon image
ASIN
B005EIH4DE (, On Amazon, On CCC)
multiple revisions of this device, use caution

FCC ID:MSQ-RTN12B
IC ID:3568A-RTN12B

CPU1:Broadcom BCM5357C0(300 MHz)
FLA1:8 MiB8,388,608 B <br />65,536 Kib <br />8,192 KiB <br />64 Mib <br />0.00781 GiB <br /> (Macronix MX25L6406EM2I-12G)
RAM1:32 MiB33,554,432 B <br />262,144 Kib <br />32,768 KiB <br />256 Mib <br />0.0313 GiB <br /> (Winbond W9425G6JH-5)

Expansion IFs: none specified
JTAG: yes, 14-pad header
Serial: yes, 4-pin header, (115200,8,N,1)

WI1 chip1:Broadcom BCM5357C0
WI1 802dot11 protocols: bgn
WI1 MIMO config: 2x2:2
WI1 antenna connector: RP-SMA

ETH chip1:Broadcom BCM5357C0
Switch:Broadcom BCM5357C0
LAN speed: 100M
LAN ports: 4
WAN speed: 100M
WAN ports: 1

Stock bootloader: CFE 5.100.138.9

TPFirmware supported:Oleg-ng (wl500g) • (List), Tomato (Shibby) • (DLs) • (List), DD-WRT • (List)

Default SSID: ASUS (93 addl. devices)
Default IP address: 192.168.1.1
the IP 192.168.1.1 is used by 1213 additional devices
of which 159 are ASUS devices
Default login user: admin
Default login password: admin
admin:admin credentials used by 1250 additional devices
of which 186 are ASUS devices

802dot11 OUI:14:DA:E9(2 E, 2 W), 30:85:A9(3 E, 3 W)
Ethernet OUI:14:DA:E9(2 E, 2 W), 30:85:A9(3 E, 3 W)

CPU1 brandWI1 chip1 brandWI1 chip2 brand
ASUS RT-N12 rev A1BroadcomBroadcom
ASUS RT-N12 rev B1BroadcomBroadcom
ASUS RT-N12 rev C1BroadcomBroadcom
ASUS RT-N12 rev D1BroadcomBroadcom
ASUS RT-N12KBroadcomBroadcom
ASUS RT-N12VPBroadcomBroadcom

For a list of all currently documented Broadcom chipsets with specifications, see Broadcom.

Wireless-N300 Router

Product page • Support page • Downloads

'P/N: 141700520029J R0B' is silkscreened on the board in the FCC photos.

The Arcadyan model on the label is WG7005F22 1-ASU.

Links of Interest

  • • Asus routers on Wikipedia
5dBi antennas
14:DA:E9 (ASUStek) OUI

Serial

Serial Pinouts

Console port J3 uses 3.3 V signaling at speed 115200.

Header is pre-installed.

Flashing

NOTE:During configuration or flashing a device, the only things that should be hooked to the device is the computer and power.

Flashing DD-WRT

Supported by dd-wrt as of dd-wrt.v24-17990

'Introduction
:Special Thanks to Eko

This install needs to be updated, I just wanted to get the page started.

Asus RT-N12 is now supported. Actually it is quite good router for its price.

If you don't need USB and Giga ethernet and 5GHz, it is good alternative

to e.g. Linksys wrt160nv3 etc..

It has bcm4716b0 cpu, 4MB flash and 32MB ram + 2 external removable antennas.

Please don't flash any old builds.

Ok, here it is.. something to start with... then simple GUI update will do.

  • dd-wrt.v24-14929_NEWD-2_K2.6_mini_RT-N12.trx (Reference Thread)

For Revision B1 of the RT-N12B1 devices use this firmware image:

dd-wrt.v24-17990_NEWD-2_K2.6_mini_RT-N12B1.trx (Reference Thread)
  • There is also a revision ASUS RT-N12 rev C1 of the hardware.
For the ASUS RT-N12 rev C1: Try: dd-wrt.v24-18774_NEWD-2_K2.6_mini_RT-N12C1.trx

Check the label on the bottom of your device or view the Top left of the original ASUS firmware for your hardware revision.

Do not flash the initial firmware for a different revision of hardware than yours.
You may still be able to recover your device if it enters an infinite reboot loop
using recovery mode as a result of loading incompatible firmware.
(Hold recover button for 30 seconds when applying the power, with static IP
settings on your computer connected via ethernet)

To clear NVRAM hold down the WPS button when applying power for 30 seconds on all the RT-N12 models.

INSTALLATION INSTRUCTIONS

DO NOT use Firefox for upgrading builds! Use Internet Explorer!!!!

0. Download the firmware above and extract it to your desktop or a convenient location.

1. For simplicity, connect only the PC to one of the router's LAN ports with a normal [uplink] ethernet cable.

No other modem,computers,routers,switches, etc should be connected.

2. In order to prevent DHCP from interupting the connection, you will need to manually set the address of your PC's Network

LAN card to a STATIC IP in the same subnet of the router, such as 192.168.1.10 with subnet mask 255.255.255.0 .

Also make sure all other adapters,such as wireless, which might be seen as 'clients' by the router are disabled.

Only the main LAN connection [IP: 192.168.1.10] should be able to communicate with the router.

3. Unplug the power connector from the back of the router.

4. While pushing & holding the recessed Restore button on the back of the router,

plug the power connector back in. The Restore button is NOT the raised red WPS button.

5. When the power LED slowly blinks on and off, release the Restore button.

The router is now in 'RESCUE MODE'.

6. Use the Asus Firmware Restoration Utility [which you should have installed on the PC]

to upload the DD-WRT mini-asus.trx file from the location where you saved it.
DO NOT DISTURB THE ROUTER or PC FOR THE NEXT FEW MINUTES. BE PATIENT!

7. After the upgrade, the Utility should ask for a router reboot.

Give it AT LEAST a minute to be on the safe side before removing the power.

Then unplug the power from the router, wait 10 seconds or so and plug the power back in.

You should now be able to access the web interface.

8. Return your Net adapter properties for TCP/IP to DHCP 'Automatically Obtain IP'

9. Type 192.168.1.1 into your browser and set your username as root and pick a password.

ALTERNATE INSTALLATION METHOD FOR ASUS TO DD-WRT FW UPDATE

The steps listed above did not work for me, but these steps did.

1) Disconnect all ethernet cables from the RT-N12 except 1 going to your NIC.

2) Turn off all wireless clients (notebooks, PS3 etc...).

2a) Turn off all programs on your computer that may be trying to access the internet

- e.g. open browser tabs, IM software, etc.

3) Ensure DHCP is enabled in the ASUS firmware and retreive IP/DNS automatically is set in your NIC properties.

(When you open your IE browser it will instruct you to plug back in your WAN ISP cable,

if your PC is still seeing the router. If not, you may need to reboot router and/or PC.)

4) Do the 30/30/30 peacock method of putting your router in recovery mode.

5) Open the router IP of 192.168.1.1. The page will open to a built in browser (HTTP) recovery console.

6) Click on the link below Reboot to reset/flash the Vram.

Rt N12 Asus Router

7) Click the Browse button to browse to your DD-WRT firmware file location.

8) Click the Upload button.

The router will upload the file fairly quickly, and you will be brought to the next

screen that says 'Allow router time to reboot.' BE PATIENT this takes about 4-5 minutes.

You will see the LAN1 light turn off and notice the 'Network Cable Unplugged' windows popup

message in task bar. Wait for the light to turn back on and the PC to reconnect to router.

9) Click the 'Continue' link shown on the page.

Clicking 'Continue' forces the router to perform another reboot.

When it comes back up you will be at the DD-WRT admin login screen.

If the login screen is white and looks very basic you will need to

perform another reboot of the router by removing the power cable.

TomatoUSB

'Asus Tomato Flash Guide
Source

Note: some people say you need to install DD-WRT first. I do NOT recommend anyone to install DD-WRT first before installing Tomato on Asus routers.

  1. Download a suitable tomato firmware
  2. Install the Asus router utility from the CD that came with the router. Run Utilitysetup.exe from the CD to install it. If you no longer have the CD you can also download it from the Asus website.
  3. Disable Firewall on your computer.
  4. Disable anti-virus on your computer.
  5. Connect your computer to one of the LAN ports of the router with an ethernet cable.
  6. Assign a static IP of 192.168.1.10 and subnet mask 255.255.255.0 to your computer LAN port.
  7. Disconnect the router WAN port if you already have a cable plugged into that port.
  8. From Windows Start menu, run ASUS Utility -> RT-N Wireless Router -> Firmware Restoration.
  9. Click the Browse button and select the file that you downloaded in step #1. Don’t click the upload button yet.
  10. Put the router in recovery mode: Unplug the power cord of the router. Hold down the black Restore button using a pen (not the red button). Plug the power cord back in. Once the power light starts flashing slowing, release the Restore button. The power light should continue to flash. The flashing light means the router is ready to accept the new firmware in recovery mode.
  11. Click the upload button in the Restoration utility. If it warns about incorrect Asus firmware, ignore it. The firmware should now start uploading into the router. Don’t touch anything while the firmware is being uploaded. (Note: these steps worked when I flashed my RT-N16. However, the utility could not find my RT-N12 B1 when I tried to flash the router, although it did work for other people. After failing for more than a dozen times, I tried to perform the upload first before putting the router in recovery mode, then it finally worked. Later I tried a different unit of RT-N12 B1 strangely it could be flashed the first time using the normal procedure. If neither of these procedures work, please see the Addendum in The Wiert Corner, and the tftp method described by Simeon W in the comments section.)
  12. No matter whether the utility says the upload is completed, or it hangs at a certain percent, DO NOT PANIC, and WAIT FOR FIVE MINUTES before you do anything else.
  13. After five minutes, open a browser and go to http://192.168.1.1. Login with user “admin” (or “root”) and password “admin”. You should be logged into Tomato.
  14. Administration -> Configuration -> Restore Default Configuration -> Erase all data in NVRAM memory(thorough) -> OK (Note: there is a forum report saying this reset function does not work properly on RT-N53 – in this case, try the hardware reset button.)
  15. After it is completed, login again, enable DHCP (for Toastman Builds), change admin password, enable WiFi security if you use WiFi, plug in your WAN connection and configure it. Also take a look at the CPU frequency, you may need to manually change it if it is not correct. (Note: overclocking your router is usually not a good idea from my experience.)
  16. Change your computer LAN port back to use DHCP (dynamic address) and dynamic DNS.

Wiert Corner method

  1. pull the power plug on the RT N66U
  2. press and hold the reset button
  3. insert the power plug on the RT N66U
  4. wait for the power led to slowly blink
  5. release the reset button
  6. wait a few minutes for the modem to become stable
  7. in the mean time set your PC to these IPv4 settings: – host = 192.168.1.100 – mask = 255.255.255.0
  8. start your web-browser
  9. point your web-browser to http://192.168.1.1 (it will time out, don’t worry)
  10. press the power button to turn off the router
  11. wait a few seconds
  12. press the power button to turn on the router now your router gets into rescue mode
  13. refresh your browser so it goes to http://192.168.1.1 again
  14. upload your Tomato firmware

Factory Reset Asus Rt N12

–jeroen

TFTP method

Rt n12 asus router

Put the router into recovery mode, set a static IP address on the computer then run in the shell:

Wait several minutes while firmware transfers and router updates. Reboot twice, waiting 3 minutes in between each reboot, and the router should now have tomato installed.
